# Hướng dẫn sử dụng

## **THIẾT LẬP CHÂN ĐẾ (ĐẦU THU)**

**1. Cài đặt mặc định cho chân đế (Reciever Default)**

Quét Lần lượt các mã vạch dưới đây<br>

| ![](https://file.hstatic.net/1000246569/file/1_aa8467d02cee44b29706ca6f87edb94c_grande.png)            |
| ------------------------------------------------------------------------------------------------------ |
| <p><img src="https://file.hstatic.net/1000246569/file/2_grande.png" alt=""></p><p>Reciever Default</p> |
| ![](https://file.hstatic.net/1000246569/file/3_grande.png)                                             |

**2. Cài đặt chế độ làm việc (Working Mode)**<br>

* ***Chế độ tự động (AUTO)***: Dữ liệu sẽ được lưu trữ trong máy quét khi không có tín hiệu. Dữ liệu sẽ được truyền đến máy thu khi tín hiệu phục hồi.

![](https://file.hstatic.net/1000246569/file/1_7702dd234c894e26b978e7b8d83d7abf_grande.png)

\*Auto

* ***Chế độ trực tiếp (Immediate)***: Dữ liệu sẽ được truyền tải ngay sau mỗi lần quét. Dữ liệu sẽ bị mất ngay khi không có tín hiệu.

![](https://file.hstatic.net/1000246569/file/2_69eb6cf175424f7f9acec22dd50614bf_grande.png)

***Immediate***

**3. Cài đặt phương thức kết nối (Interface Selection)**

| ![](https://file.hstatic.net/1000246569/file/1_c7577c5085df4a3293a91bee519fa366_grande.png) |                   |
| ------------------------------------------------------------------------------------------- | ----------------- |
| ![](https://file.hstatic.net/1000246569/file/2_11cf42b77e314441a05525767c51c2ed_grande.png) | **USB/KB MODE**   |
| ![](https://file.hstatic.net/1000246569/file/3_9baa85ae52524d27a45923e0b123cfed_grande.png) | **RSS232 MODE**   |
| ![](https://file.hstatic.net/1000246569/file/4_grande.png)                                  | **\*Auto choose** |
| ![](https://file.hstatic.net/1000246569/file/5_grande.png)                                  |                   |

**4. Cài đặt xuống dòng cho đầu đọc mã vạch**

| ![](https://file.hstatic.net/1000246569/file/1_958e8e073d0f4fc4bd7c3d52709fe996_grande.png) |                  |
| ------------------------------------------------------------------------------------------- | ---------------- |
| ![](https://file.hstatic.net/1000246569/file/2_0db461653c4543cb8adf7118034ac75e_grande.png) | **None**         |
| ![](https://file.hstatic.net/1000246569/file/3_580f86d4b43f48cabed4160e4520a2b4_grande.png) | **Tab(0D0A)**    |
| ![](https://file.hstatic.net/1000246569/file/4_eda07ea000c64d5ea9a9212491c6603c_grande.png) | **\*Enter (0D)** |
| ![](https://file.hstatic.net/1000246569/file/5_d7978c93bffb47afa6ff255b67271ab8_grande.png) | **Space (20)**   |
| ![](https://file.hstatic.net/1000246569/file/6_grande.png)                                  | **Return(0A)**   |
| ![](https://file.hstatic.net/1000246569/file/7_grande.png)                                  |                  |

**5. Âm bíp đế thu (thiết bị nhận)**

| ![](https://file.hstatic.net/1000246569/file/1_c2bd2116e6b44f709ab266af184b350b_grande.png) |            |
| ------------------------------------------------------------------------------------------- | ---------- |
| ![](https://file.hstatic.net/1000246569/file/2_f98e21c9c97e484a9f92a991e794eb62_grande.png) | **Mute**   |
| ![](https://file.hstatic.net/1000246569/file/3_bb405bc3babb4d369815825119a48cb1_grande.png) | **\*On**   |
| ![](https://file.hstatic.net/1000246569/file/4_eeaec08563ed46a388463975011215bf_grande.png) | **Low**    |
| ![](https://file.hstatic.net/1000246569/file/5_afbc30c0c4aa4334995a1d316017971a_grande.png) | **Medium** |
| ![](https://file.hstatic.net/1000246569/file/6_bf29f74b1aef4b20a4b928c4d2fef2c9_grande.png) | **\*High** |
| ![](https://file.hstatic.net/1000246569/file/7_b0acd5a2880844cb8088d1f2d4f31c93_grande.png) |            |

**6. Âm cảnh báo chuyển dữ liệu**

| ![](https://file.hstatic.net/1000246569/file/1_1252100ac7b64d95a3fe241c01c7cb0b_grande.png) |           |
| ------------------------------------------------------------------------------------------- | --------- |
| ![](https://file.hstatic.net/1000246569/file/2_b9b9a7100fba4d5697833115daa2d39d_grande.png) | **\*OFF** |
| ![](https://file.hstatic.net/1000246569/file/3_ea656a192047479daa59692e6637de2f_grande.png) | **ON**    |
| ![](https://file.hstatic.net/1000246569/file/4_d45e7abb89c5409aa7aaf8dc0d12b650_grande.png) |           |

**THIẾT LẬP ĐẦU ĐỌC**

**1. Cài đặt mặc định đầu đọc**

| ![](https://file.hstatic.net/1000246569/file/1_97a90c5d44bf494e8075c2fce116e7bd_grande.png) | **Bước 01: start**            |
| ------------------------------------------------------------------------------------------- | ----------------------------- |
| ![](https://file.hstatic.net/1000246569/file/2_ee9737c64b7443059609db91439043e1_grande.png) | **Bước 02: Reset**            |
| ![](https://file.hstatic.net/1000246569/file/3_ed9f001fe91e43329fdbe03b99ded4ed_grande.png) | **Bước 03: Start**            |
| ![](https://file.hstatic.net/1000246569/file/4_fbe0628eff604f96b6b547d8aee39a07_grande.png) | **Bước 04: RS232 mode**       |
| ![](https://file.hstatic.net/1000246569/file/5_24781a61328242f4a88f1d1e353fc77c_grande.png) | **Bước 05: End**              |
| ![](https://file.hstatic.net/1000246569/file/6_c3dc7e4b7d3b4870a754138b4f607189_grande.png) | **Bước 06: Link scanner**     |
| ![](https://file.hstatic.net/1000246569/file/7_0ed6bed875244eebb221f998d4941a24_grande.png) | **Bước 07: Receiver Default** |

**2. Tiếng beep đầu đọc**

| ![](https://file.hstatic.net/1000246569/file/1_75865e39d66c4cbdbbebedf09702e366_grande.png) | **Start**   |
| ------------------------------------------------------------------------------------------- | ----------- |
| ![](https://file.hstatic.net/1000246569/file/2_58e3cacffbbc4f1cb2c2bdb292bb3f3e_grande.png) | **OFF**     |
| ![](https://file.hstatic.net/1000246569/file/3_f8cb5d9c083744f9a05ddce05f285ac5_grande.png) | **\*ON**    |
| ![](https://file.hstatic.net/1000246569/file/4_f0c61c0851db439691d831d82558db77_grande.png) | **Low**     |
| ![](https://file.hstatic.net/1000246569/file/5_d15ab3f3e3cd497cb06d44c5f42c1b8e_grande.png) | **Medium**  |
| ![](https://file.hstatic.net/1000246569/file/6_21dc3fc0a1ae4a92b6e0b74ae2c61f70_grande.png) | **\*Hight** |
| ![](https://file.hstatic.net/1000246569/file/7_19ad64f2f96e4372a1a7b2a894f1daff_grande.png) | **End**     |

**3. Chế độ đọc**

| ![](https://file.hstatic.net/1000246569/file/1_5ebf0adf622940d89a07ac702abe3bb6_grande.png) | **Start**          |
| ------------------------------------------------------------------------------------------- | ------------------ |
| ![](https://file.hstatic.net/1000246569/file/2_4e5a3dd78baa440a85300ba2a8a4b265_grande.png) | **Manual Mode**    |
| ![](https://file.hstatic.net/1000246569/file/3_d5a0af7349f4487b91c10554059424c6_grande.png) | **Automatic Mode** |
| ![](https://file.hstatic.net/1000246569/file/4_62a3762471194c88b4354f20c62679d4_grande.png) | **End**            |

**4. Cài đặt chế độ đọc code39**

| ![](https://file.hstatic.net/1000246569/file/1_80fa1c5290734747bb01c0e01cec7504_grande.png) | **Start**             |
| ------------------------------------------------------------------------------------------- | --------------------- |
| ![](https://file.hstatic.net/1000246569/file/2_f6e3290c6388469f8637bdb38f0ef61e_grande.png) | **Transfer**          |
| ![](https://file.hstatic.net/1000246569/file/3_c8f0a02b35f64430b8cbeb14df063d0b_grande.png) | **\*Do not transfer** |
| ![](https://file.hstatic.net/1000246569/file/4_792561de9c5b4e5f8e5f05a4267b5d06_grande.png) | **End**               |

Mọi thắc mắc các bạn có thể để  lại comment bên dưới, [**Hacode**](https://hacode.vn/) sẽ hỗ trợ trả lời các bạn trong thời gian sớm nhất.
